Victron 12/24/48V 85A SmartSolar MPPT 150/85-Tr VE.CAN Bluetooth Solar Charge Controller

Victron SmartSolar MPPT 150/85-Tr VE.CAN (12/24/48V)

Serious Solar Power for Large, Demanding Systems

When your system demands maximum current, absolute reliability, and advanced system integration, the Victron SmartSolar MPPT 150/85-Tr VE.CAN delivers without compromise.

Ultra-Fast MPPT = More Power, Faster

Victron’s industry-leading ultra-fast Maximum Power Point Tracking continuously adapts to rapidly changing light conditions:

• Up to 30% more energy than PWM controllers
• Up to 10% more yield than slower MPPTs
• Exceptional performance on cloudy days and variable sunlight

Every second of sunlight is converted into usable energy.

 Superior Performance in Partial Shading

Unlike conventional MPPT controllers that can lock onto a local (less efficient) power point, SmartSolar’s advanced MPPT algorithm:

• Detects multiple power points
• Automatically locks onto the true optimal MPP
• Maximises output even when panels are partially shaded

High-Current Charging for Large Battery Banks

With a powerful 85A output, the 150/85 is ideal for:

• Large lithium battery banks
• High-capacity lead-acid systems
• Multi-panel, high-voltage solar arrays

Perfect for systems where scalability and speed matter.

 Smart Control, Built-In

No dongles. No extra hardware.

Bluetooth Smart comes standard, allowing you to:

• Monitor real-time performance
• Adjust charging settings
• Update firmware wirelessly
• Diagnose issues instantly


Silent. Cool. Ultra-Efficient.

• No cooling fan → completely silent operation
• 98%+ peak efficiency
• Minimal heat generation, maximum reliability

Designed for continuous operation in harsh environments.

Industrial-Grade Protection

Your system stays protected with:

• Over-temperature protection & power derating
• PV short-circuit protection
• PV reverse polarity protection
• PV reverse current protection

Built to handle real-world conditions—day after day.

 Fully Customisable Charging

Tailor charging precisely to your battery setup:

• Fully programmable charge algorithms
• 8 pre-programmed profiles selectable via rotary switch
• Automatic temperature-compensated charging via internal sensor

Optimised charging = longer battery life.

VE.CAN & System Integration

Designed for advanced Victron systems:

• VE.CAN networking for multi-controller setups
• VE.Direct for wired monitoring & data connections
• Remote on/off support (e.g. VE.BUS BMS integration)
